PCA9515BDGKR Real Image PCA9515BDGKR real image4501 PCA9515BDGKR real image4502 PCA9515BDGKR Real Image1 PCA9515BDGKR Real Image2 PCA9515BDGKR Real Image3
Same model may have multiple batches, images only for reference.
PCA9515BDGKR Real Image PCA9515BDGKR real image4501 PCA9515BDGKR real image4502 PCA9515BDGKR Real Image1 PCA9515BDGKR Real Image2 PCA9515BDGKR Real Image3
PCA9515BDGKR Real Image PCA9515BDGKR real image4501 PCA9515BDGKR real image4502 PCA9515BDGKR Real Image1 PCA9515BDGKR Real Image2 PCA9515BDGKR Real Image3
Same model may have multiple batches, images only for reference.

PCA9515BDGKR

Part No PCA9515BDGKR
Manufacturer Texas Instruments
Catalog Interface - Signal Buffers, Repeaters, Splitters
Description IC REDRIVER I2C 1CH 8VSSOP
Datasheet
PCA9515BDGKR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Buffer, ReDriver
Applications I2C
Input 2-Wire Bus
Output 2-Wire Bus
Data Rate (Max) 400kHz
Number of Channels 1
Capacitance - Input 7pF
Supply Voltage - Operating 2.3 V to 3.6 V
Operating Supply Current 500μA
Temperature Range - Operating -40°C to 85°C
Case / Package 8-VSSOP
Win Source Part Number 026451-PCA9515BDGKR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PCA9515BDGKR CAD Model

Description

The PCA9515BDGKR is a high-performance integrated circuit (IC) manufactured by Texas Instruments, a leading global semiconductor company.

  • Product: PCA9515BDGKR
  • Manufacturer: Texas Instruments
  • Description: Differential bidirectional I2C bus and SMBus repeater
  • Package: 8-pin VSSOP (DGK) package
  • Operating Temperature Range: -40°C to 85°C
  • Supply Voltage Range: 2.3V to 5.5V
  • Feature: Ability to isolate capacitance
  • Support: Standard (100 kHz) and fast (400 kHz) I2C bus data rates
  • Feature: Hot-insertion circuit
  • ESD protection: Exceeding 2000 V HBM per JESD22-A114, 200 V MM per JESD22-A115 and 1000 V CDM per JESD22-C101
