Same model may have multiple batches, images only for reference.

OPA140AID

Name: OPA140AID
Brand: Texas Instruments
SKU: 263142
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	OPA140AID
Manufacturer	Texas Instruments
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP JFET 11MHZ RRO SOT23-5
Datasheet	OPA140AID Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Amplifier Type	J-FET
Number of Circuits	1
Output Type	Rail-to-Rail
Slew Rate	20 V/μs
Gain Bandwidth Product (GBP)	11MHz
Current - Input Bias	0.5pA
Voltage - Input Offset	30μV
Operating Supply Current	1.8mA
Channel Output Current	36mA
Supply Voltage - Operating	4.5 V to 36 V, ±2.25 V to 18 V
Temperature Range - Operating	-40°C to 125°C
Mounting	SMD (SMT)
Case / Package	SOT-23-5
Win Source Part Number	081977-OPA140AID
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Power Management, Industrial, Medical
Ultra Librarian 3D Model	Ultra Librarian OPA140AID CAD Model

Alternative Products

Description

The OPA140AID is a high-performance, single operational amplifier (op-amp) produced by Texas Instruments, a globally recognized leader in the field of semiconductors.

Single Supply Voltage Range: 4.5V to 36V
Dual Supply Voltage Range: ±2.25V to ±18V
Distortion: 0.0002% @ 1kHz
Noise Performance: 10nV/√Hz @ 1kHz
Open-Loop Gain: 120dB
Bandwidth: 11MHz
Slew Rate: 20V/µs
Input Bias Current: 10pA
Package: 8-pin SOIC
Temperature Range: -40°C to +125°C
