Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Type Receiver
Protocol RS422, RS423
Number of Drivers/Receivers 0/4
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 082996-MC3486D
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MC3486D CAD Model

Description

Product MC3486D from Texas Instruments is an advanced, high-quality electronic component designed to offer optimal performance in a variety of applications.

  • Function: Quadruple differential line receiver
  • Compatibility: ANSI Standards TIA/EIA-422-B-1994 and ITU Recommendation V.11
  • Operating Rate: Up to 10 Mbit/s
  • Key Feature: High input impedance
  • Fail-safe Design: Ensures a logic-high output if the inputs are open or shorted
  • Supply Voltage Range: 4.75V to 5.25V
  • Operating Temperature Range: -40°C to 85°C
  • Package: 16-pin SOIC package
