Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 021525-MAX3232IDBR
Family Name MAX3232
Introduction Date February 01, 1996
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3232IDBR CAD Model

Description

The MAX3232IDBR is a high-performance product from Texas Instruments, a renowned leader in semiconductor technology.

  • Series: MAX3232
  • Voltage Supply: Single 3.0V to 5.5V
  • Drivers: 2
  • Receivers: 2
  • Driver Output Swing: ±9.0V from 3.0V supply
  • Receiver Input Levels: Up to ±30V
  • Shutdown Mode Current: 1µA
  • Transmitter Output Stage: Low-dropout
  • Automatic Power-Down: Yes
  • ESD Protection (RS-232 Pins): ±15kV
  • Package: 16-pin SSOP
