Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 021517-MAX3232EIDBR
Family Name MAX3232E
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3232EIDBR CAD Model

Description

The MAX3232EIDBR is a high-quality product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Product Type: 2/2 Transceiver
  • Series: MAX3232
  • Voltage Range: 3.0 V to 5.5 V
  • Auto-Power-Down: Yes
  • Data Rate: 250 kbps
  • ESD Protection: Up to ±15 kV
  • Package: 16-SSOP (DBR)
  • Operating Temperature: -40°C to 85°C
  • Compatibility: RS-232 Applications
  • Compliance: RoHS Compliant
