Category Integrated Circuits(ICs)
Family Interface - Drivers, Receivers, Transceivers
Manufacturer Texas Instruments
Packaging Tube
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 500mV
Data Rate 250kbps
Operating Supply Voltage 3 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting Style SMD/SMT
Package 16-SSOP (0.209", 5.30mm Width)
Manufacturer Device Package 16-SSOP
Win Source Part Number 143119-MAX3221IDB
Ultra Librarian 3D Model Ultra Librarian MAX3221IDB CAD Model

Description

The MAX3221IDB is a high-quality, reliable product developed by Texas Instruments, a renowned global semiconductor company that designs and manufactures analog, embedded processing, and digital signal processing solutions.

  • Type: Single-channel RS-232 transceiver
  • Operating Voltage: 3.0V to 5.5V
  • Data Rates: 120kbps
  • ESD Protection: Exceeding ±15kV using IEC 61000-4-2 Air-Gap Discharge, ±8kV using IEC 61000-4-2 Contact Discharge, and ±15kV using Human-Body Model
  • Package: 16-pin SSOP (DB) package
