LMX2571NJKR

Part No LMX2571NJKR
Manufacturer Texas Instruments
Catalog Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description IC SYNTHESIZER W/FSK MOD 36WQFN / LMX2571 Low-Power, High-Performance PLLatinum™ RF Synthesizer
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Packaging Reel
Type Frequency Synthesizer (RF)
PLL Yes with Bypass
Input Clock, Crystal
Output Clock
Number of Circuits 1
Frequency - Max 1.4GHz
Divider/Multiplier Yes/Yes
Supply Voltage (V) 3.15V ~ 3.45V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 36-WFQFN Exposed Pad
Supplier Device Package 36-WQFN (6x6)
Manufacturer Pack Quantity 2,500
MSL Level 3 (168 Hours)
Popularity High
Supply and Demand Status Balance
Win Source Part Number 802396-LMX2571NJKR
Ultra Librarian 3D Model Ultra Librarian LMX2571NJKR CAD Model

Description

The LMX2571NJKR from Texas Instruments is a highly integrated, wideband frequency synthesizer that delivers exceptional performance in a compact package. This advanced synthesizer is designed to meet the demanding requirements of wireless infrastructure, test and measurement, and aerospace and defense applications. With its broad frequency range and low phase noise, the LMX2571NJKR is an ideal choice for designers looking to optimize their RF systems.

Key Features:

  • Wide Frequency Range: The device supports a wide frequency range of 10 MHz to 1344 MHz in the integer-N mode and 10 MHz to 1080 MHz in the fractional-N mode, making it suitable for a variety of applications.
  • Low Phase Noise: The LMX2571NJKR boasts low phase noise performance, which is critical for high-performance RF systems that require clean signal generation.
  • Integrated VCO: The inclusion of an integrated wideband voltage-controlled oscillator (VCO) simplifies design and reduces the number of external components required.
  • Programmable Output Power: The output power is programmable, allowing designers to optimize the performance for their specific application.
  • MultiSynth Technology: Texas Instruments' innovative MultiSynth technology enables fine frequency resolution, which is essential for applications that demand high precision.

Applications:

  • Wireless Infrastructure (e.g., base stations, backhaul)
  • Test and Measurement Equipment
  • Aerospace and Defense Systems
  • Satellite Communications

The LMX2571NJKR is available in a compact 32-pin WQFN package, which is designed to minimize the footprint on the PCB and is suitable for space-constrained applications. Its advanced features and versatility make it an excellent choice for engineers and designers looking to push the boundaries of RF and microwave system performance.

With Texas Instruments' commitment to quality and long-term reliability, the LMX2571NJKR represents a robust and flexible solution for high-frequency synthesizer design challenges.
