LMP7704MTX/NOPB Real Image LMP7704MTX/NOPB Real Image
Same model may have multiple batches, images only for reference.
LMP7704MTX/NOPB Real Image LMP7704MTX/NOPB Real Image
LMP7704MTX/NOPB Real Image LMP7704MTX/NOPB Real Image
Same model may have multiple batches, images only for reference.

LMP7704MTX/NOPB

Part No LMP7704MTX/NOPB
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 2.5MHZ RRO 14TSSOP
Datasheet
LMP7704MTX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 1.1 V/μs
Gain Bandwidth Product (GBP) 2.5MHz
Current - Input Bias 0.2pA
Voltage - Input Offset 37μV
Operating Supply Current 3.2mA
Channel Output Current 86mA
Supply Voltage - Operating 2.7 V to 12 V, ±1.35 V to 6 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 14-TSSOP
Win Source Part Number 127262-LMP7704MTX/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LMP7704MTX/NOPB CAD Model

Description

The LMP7704MTX/NOPB is a high-quality, precision operational amplifier from Texas Instruments. This product is a quad operational amplifier that operates with a single supply voltage.

  • Features: Rail-to-rail input/output, high gain bandwidth of 17MHz, low input bias current 1pA, low input offset voltage of 180µV, high precision and robust operation, shutdown mode for energy efficiency
  • Temperature Range: -40°C to 125°C
  • ESD Protection: 2kV
  • Package: 8-pin VSSOP
  • Applications: Precision instrumentation, data acquisition systems, medical equipment, active filter circuits
