Product Overview: LMH0303SQ/NOPB

The LMH0303SQ/NOPB is a high-performance, low-power, SDI cable driver from Texas Instruments. It is designed to support SMPTE 259M, SMPTE 344M, SMPTE 292M, and SMPTE 424M serial digital video standards. This makes it a versatile component for broadcasting, professional video editing, and studio equipment where high-definition video data transmission is required.

Key Features

• High Data Rates: The LMH0303SQ/NOPB supports data rates up to 2.97 Gbps, ensuring compatibility with standard and high-definition video signals.
• Power Efficiency: With a typical power consumption of only 105 mW at 2.97 Gbps, it is designed for power-sensitive applications.
• Integrated Cable Driver: The device includes an integrated cable driver with a 75Ω output, simplifying the design of SDI video interfaces.
• Flexibility: The output swing is programmable through an external pin, providing flexibility to optimize the performance for various cable lengths.
• Robustness: It features an integrated input equalizer that compensates for up to 20 dB of cable loss, ensuring signal integrity over long cable runs.

Applications

The LMH0303SQ/NOPB is ideal for a range of applications, including:

• High-definition video cameras
• Video switchers
• Distribution amplifiers
• Video editing and post-production equipment

Quality and Reliability

As with all Texas Instruments products, the LMH0303SQ/NOPB is manufactured to the highest quality standards. The device is available in a compact, 16-pin WQFN package, and its lead-free construction complies with RoHS requirements, ensuring both performance and environmental responsibility.

Ordering Information

The product is available under the part number LMH0303SQ/NOPB. For detailed specifications, application notes, and ordering information, please visit the Texas Instruments website or contact your local Texas Instruments sales representative.
