LM6134AIM Texas Instruments LM6134AIM Real Image LM6134AIM Real Image LM6134AIM real image 2 LM6134AIM label picture LM6134AIM label picture 2
Same model may have multiple batches, images only for reference.
LM6134AIM Texas Instruments LM6134AIM Real Image LM6134AIM Real Image LM6134AIM real image 2 LM6134AIM label picture LM6134AIM label picture 2
LM6134AIM Texas Instruments LM6134AIM Real Image LM6134AIM Real Image LM6134AIM real image 2 LM6134AIM label picture LM6134AIM label picture 2
Same model may have multiple batches, images only for reference.

LM6134AIM

Part No LM6134AIM
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description Op Amp Quad Low Power Amplifier R-R I/O 24V 14-Pin SOIC Tube / IC OPAMP GP 11MHZ RRO 14SOIC
Datasheet
LM6134AIM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 14 V/μs
Gain Bandwidth Product (GBP) 11MHz
Current - Input Bias 125nA
Voltage - Input Offset 1.7mV
Operating Supply Current 390μA
Channel Output Current 3.5mA
Supply Voltage - Operating 1.8 V to 24 V, ±0.9 V to 12 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 082835-LM6134AIM
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LM6134
Introduction Date April 01, 2000
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LM6134AIM CAD Model

Description

The LM6134AIM from Texas Instruments is a high-performance, quad operational amplifier designed to meet the demanding requirements of today's sophisticated electronic systems.

  • Operating Voltage: Wide supply voltage range of 2.7V to 16V
  • Slew Rate: 10V/us
  • Gain-Bandwidth Product: 10MHz
  • Input and Output Swing: Rail-to-rail input and output swing
  • Power Efficiency: Low supply current of 1.1mA per amplifier
  • Output Drive Capability: High output drive capability of 80mA
  • Package: Compact 14-pin SOIC package
