Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type General Purpose
Number of Elements 1
Output Type CMOS, Open-Collector, TTL
Supply Voltage - Operating 5 V to 30 V, ±2.5 V to 15 V
Voltage - Input Offset (Max) 7mV @ 30V
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 13mA @ 5V
Current - Quiescent (Max) 2mA
Propagation Delay (Max) 940μs
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 082758-LM397MF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Signal Processing
Family Name LM397
Introduction Date June 01, 2001
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LM397MF CAD Model

Description

The LM397MF is a high-quality, high-performance voltage comparator produced by Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Supply Voltage Range: 2V to 36V (single), ±1V to ±18V (dual)
  • Voltage Gain: 200,000
  • Bandwidth: 1.3MHz
  • Differential Input Voltage Range: Equal to the power supply voltage
  • Output Voltage Compatibility: TTL, MOS, and CMOS logic systems
  • Input Offset Voltage: Low
  • Input Offset Current: Low
  • Input Bias Current: Low
  • Power Consumption: Low
  • Package: SOT-23
