Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Pulse Width Distortion (Max) 1ns
Rise and Fall Time 1ns, 1ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 002051-ISO722MD
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ISO722MD CAD Model

Description

The ISO722MD from Texas Instruments is a high-performance, robust digital isolator designed to provide superior electrical isolation and signal integrity.

  • Channels: Dual-channel
  • Data Rates: Up to 1 Mbps
  • Isolation Technology: Proprietary capacitive isolation technology
  • Isolation Barrier: Can withstand voltage transients up to 4 kV peak
  • Supply: Single 3.3 V or 5 V supply
  • Package: Compact 8-pin SOIC package
  • Operating Temperature Range: -40°C to +125°C
  • Safety Standards: UL 1577 and IEC 60747-5-2
