Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Obsolete(EOL)
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 2/2
Channel Type Bidirectional
Isolation Voltage 1500Vrms
Common Mode Transient Immunity (Min) 1.6kV/μs (Typ)
Data Rate 80MBd
Propagation Delay tpLH / tpHL (Max) 40ns, 40ns
Pulse Width Distortion (Max) 6ns
Rise and Fall Time 9ns, 9ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Case / Package 12-SOP
Win Source Part Number 018116-ISO150AU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name ISO150
Introduction Date June 01, 2005
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian ISO150AU CAD Model

Description

The ISO150AU is a high-quality, high-performance product from Texas Instruments, a renowned global semiconductor company that designs and manufactures analog, embedded processing, and other types of chips.

  • Key Features: High input-impedance differential amplifier and an output amplifier
  • Maximum Working Voltage: Up to 1000 Vrms
  • Bandwidth: DC to 50 kHz
  • Package: Compact, surface-mount
  • Power Consumption: Low
