Product Overview: INA186A1IYFDR by Texas Instruments

The INA186A1IYFDR is a precision, low-power, current-sense amplifier from Texas Instruments, designed to provide accurate current measurement for a wide range of applications. This high-quality component is part of the industry-leading INA186 family, known for its reliability and performance in current-sensing solutions.

Key Features

• High Accuracy: The INA186A1IYFDR offers a gain error of only ±0.1% (max), ensuring precise current measurement for critical applications.
• Wide Common-Mode Range: It operates over a common-mode voltage range from -0.2V to +26V, making it versatile for various systems with different voltage levels.
• Low Quiescent Current: With a quiescent current of only 260 µA (typical), this current-sense amplifier is ideal for power-sensitive applications.
• Adjustable Gain: The device features an adjustable gain set by external resistors, allowing customization for specific application needs.
• High Bandwidth: It offers a bandwidth of up to 350 kHz, which is suitable for fast current-sensing applications.

Applications

The INA186A1IYFDR is designed for a variety of applications across different industries. It is particularly well-suited for:

• Power management in consumer electronics
• Overcurrent protection circuits
• Battery chargers and management systems
• Automotive and industrial monitoring systems

Package and Quality

This current-sense amplifier is offered in a compact 6-pin SOT-23 package, which is suitable for space-constrained applications. The INA186A1IYFDR is also supported by Texas Instruments' commitment to quality, ensuring high reliability and performance consistent with industry standards.

Design Support

Texas Instruments provides extensive design support for the INA186A1IYFDR, including application notes, reference designs, and simulation tools. These resources help designers to reduce development time and ensure a smooth integration process into their projects.
