Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Power MOSFET
Applications Battery Powered
Output Current 1A
Supply Voltage - Operating 2.75 V to 6.8 V
Voltage - Load 2.75 V to 6.8 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 10-VSON (3x3)
Win Source Part Number 1034166-DRV8830DRCT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DRV8830DRCT CAD Model

Description

The DRV8830DRCT from Texas Instruments is a highly integrated motor driver designed specifically for driving small brushed DC motors. It offers a compact and efficient solution for portable and space-constrained applications, such as consumer electronics, toys, and personal healthcare devices.

Key Features

  • Voltage Range: The device operates from a power supply voltage range of 2.75V to 6.8V, making it suitable for battery-powered applications where power efficiency is crucial.
  • Output Drive Capability: It can deliver up to 1A of output current, providing sufficient power for small motors.
  • I²C Control Interface: The DRV8830DRCT features an I²C-compatible interface that allows for easy control over the motor's speed and direction, as well as the ability to program different acceleration and deceleration profiles.
  • Integrated Protection Features: The device includes multiple protection features such as over-current, thermal shutdown, under-voltage lockout, and open-load detection, ensuring reliable operation and longevity of the motor and the driver.
  • Low Power Consumption: It has a low standby current, which is essential for battery-powered applications where extending battery life is a priority.

Applications

The DRV8830DRCT is versatile and can be used in a variety of applications. Its small size and power efficiency make it an ideal choice for:

  • Battery-operated toys
  • Personal healthcare devices
  • Portable electronics
  • Small robotics projects

Package and Quality

This motor driver is available in a small 2x2mm WSON package, which is designed for space-constrained applications. The DRV8830DRCT is also RoHS compliant and is designed to meet the stringent quality standards set by Texas Instruments, ensuring high reliability and performance.

With its compact form factor, ease of use, and integrated safety features, the DRV8830DRCT is an excellent choice for designers looking to add motor control capabilities to their next project.
