The CD4093BQM96G4Q1 is a high-grade integrated circuit from Texas Instruments, designed for automotive and other applications requiring robust, reliable components. This device is part of the 4000 series CMOS logic family, featuring quad two-input NAND Schmitt triggers. The unique characteristic of Schmitt triggers is their hysteresis function, which enables the circuit to handle slow input transition signals with increased noise immunity.

Each of the four independent NAND gates in the CD4093BQM96G4Q1 operates with a wide voltage range from 3V to 18V, making this IC suitable for interfacing with various logic levels, from TTL to CMOS. The device's standardized symmetrical output characteristics ensure consistent performance, while its high noise immunity of typically 0.45 VDD (VDD = 10V) is a testament to its robust design.

The CD4093BQM96G4Q1 is housed in a compact QFN-20 package, which is ideal for space-constrained applications. The package is designed to meet the stringent requirements of the automotive industry and is qualified for use in automotive applications, adhering to the AEC-Q100 standards for reliability and performance under extreme conditions.

Key features of the CD4093BQM96G4Q1 include:

• Quad two-input Schmitt trigger NAND gates
• Wide operating voltage range (3V to 18V)
• High noise immunity
• Low power consumption
• Medium speed operation - typical tPHL, tPLH of 15ns with 10V supply
• Matched rise and fall times
• Compliant with AEC-Q100 automotive standards
• Compact QFN-20 package for space-saving design

Applications for the CD4093BQM96G4Q1 are diverse and include automotive systems, alarm circuits, logic signal conditioning, pulse shaping, and delay functions among others. Its ability to handle slow or noisy inputs makes it particularly useful in environments with high electrical interference.

Overall, the CD4093BQM96G4Q1 from Texas Instruments is a versatile, reliable choice for designers seeking a high-performance Schmitt trigger NAND gate IC that meets the rigorous demands of automotive and industrial applications.
