ATL431BQDBZR

Part No ATL431BQDBZR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Reference
Description IC VREF SHUNT ADJ 0.5% SOT23-3 / Shunt Voltage Reference IC Adjustable 2.5V 36 VV ±0.5% 100 mA SOT-23-3
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Reference
Mfr Texas Instruments
Package Tape & Reel
Product Status Active
Reference Type Shunt
Output Type Adjustable
Voltage - Output (Min/Fixed) 2.5V
Voltage - Output (Max) 36 V
Current - Output 100 mA
Tolerance ±0.5%
Temperature Coefficient 82ppm/°C
Current - Cathode 35 µA
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23-3
Base Product Number ATL431
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 852005-ATL431BQDBZR
Ultra Librarian 3D Model Ultra Librarian ATL431BQDBZR CAD Model

Description

Introducing the ATL431BQDBZR from Texas Instruments

The ATL431BQDBZR is a versatile and precise adjustable shunt voltage reference from Texas Instruments (TI), a global semiconductor company known for its innovative and reliable products. This device is part of TI's extensive portfolio of voltage references that cater to a wide range of applications, offering designers flexibility and high performance in their circuit designs.

This precision voltage reference comes in a small, surface-mount package, making it ideal for space-constrained applications. It is designed to be flexible, allowing users to set the output voltage with external resistors from Vref to 36V, with the Vref being typically 2.5V. This feature makes it suitable for various applications, including power supplies, battery chargers, and voltage monitoring systems.

The ATL431BQDBZR operates with a low typical dynamic impedance of 0.22 ohms, contributing to stable output voltage despite changes in load conditions. This low impedance, combined with a wide operating current range of 100µA to 100mA, ensures that the device can be used in a diverse set of applications requiring a stable reference voltage over a broad spectrum of operating conditions.

With its wide operating temperature range of -40°C to 125°C, the ATL431BQDBZR is designed to perform reliably in harsh environments, making it suitable for industrial and automotive applications where temperature extremes are common. Additionally, the device features excellent temperature stability, ensuring that the voltage reference remains consistent across the entire temperature range.

Safety and reliability are paramount in circuit design, and the ATL431BQDBZR addresses these concerns with its built-in overcurrent protection. This feature helps to prevent damage to the device and the application it is used in, should an unexpected current surge occur.

In summary, the ATL431BQDBZR adjustable shunt voltage reference from Texas Instruments is a high-performance solution for designers seeking a stable, precise, and flexible voltage reference. Its compact form factor, robust temperature performance, and safety features make it an excellent choice for a myriad of applications across various industries.
