ADS1254E/2K5 Real Image ADS1254E/2K5 real image1546
Same model may have multiple batches, images only for reference.
ADS1254E/2K5 Real Image ADS1254E/2K5 real image1546
ADS1254E/2K5 Real Image ADS1254E/2K5 real image1546
Same model may have multiple batches, images only for reference.

ADS1254E/2K5

Part No ADS1254E/2K5
Manufacturer Texas Instruments
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC 24BIT SER 20.8KHZ 20-QSOP
Datasheet
ADS1254E/2K5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of Bits 24
Sampling Rate 20k
Number of Inputs 4
Input Type Differential
Data Interface SPI
Configuration MUX-ADC
Number of A/D Converters 1
Reference Type External
Analog Supply Voltage 5V
Digital Supply Voltage 1.8 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Case / Package 20-SSOP/QSOP
Win Source Part Number 009275-ADS1254E/2K5
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ADS1254E/2K5 CAD Model

Description

ADS1254E/2K5 - High-Performance Multi-Channel ADC

Building on the capabilities of the ADS1254E, the ADS1254E/2K5 delivers enhanced multi-channel data processing with better integration options. Its flexible architecture supports extensive customization to meet specific application needs.

  • Applications: Complex data acquisition systems, Networked sensor arrays, Test and measurement equipment
  • Features and Benefits:
    • Enhanced multi-channel processing for comprehensive data acquisition
    • Improved integration features for ease of design
    • Low power consumption for efficiency in large-scale deployments
    • Rugged construction for reliable performance in field applications

The ADS1254E/2K5 is engineered for demanding applications that need reliable, high-speed multi-channel data capture.
