ADS1244IDGSRG4

Part No ADS1244IDGSRG4
Manufacturer Texas Instruments
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC LP CONVERT 24BIT 10-MSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of Bits 24
Sampling Rate 15
Number of Inputs 1
Input Type Differential, Single Ended
Data Interface SPI
Configuration ADC
Number of A/D Converters 1
Reference Type External
Analog Supply Voltage 2.5 V to 5.25 V
Digital Supply Voltage 1.8 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Case / Package 10-VSSOP
Win Source Part Number 198764-ADS1244IDGSRG4
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADS1244IDGSRG4 CAD Model

Description

Product Overview

The ADS1244IDGSRG4 is a high-precision 24-bit analog-to-digital converter (ADC) designed to provide exceptional performance for a wide range of applications. Its robust architecture and advanced features make it an ideal choice for low-noise signal processing tasks.

Features and Benefits

  • High Resolution: 24-bit resolution for precise measurements.
  • Low Power Consumption: Suitable for battery-operated systems with efficient power management.
  • Compact Package: Available in a small-form-factor package, saving space in compact designs.
  • High Input Impedance: Ensures minimal loading of input sources.
  • Temperature Range: Operates over an extended temperature range for reliable performance across various environments.

Applications

  • Medical Device Monitoring
  • Industrial Process Control
  • Weigh Scales
  • Data Acquisition Systems
  • Scientific Instrumentation

Additional Details

The ADS1244IDGSRG4 combines performance and reliability, making it suitable for use in noise-sensitive environments. Its versatile configuration options allow for seamless integration into diverse application fields, ensuring optimal signal acquisition and accuracy.
