RTE24012F TE Connectivity RTE24012F Real Image
Same model may have multiple batches, images only for reference.
RTE24012F TE Connectivity RTE24012F Real Image
RTE24012F TE Connectivity RTE24012F Real Image
Same model may have multiple batches, images only for reference.

RTE24012F

Part No RTE24012F
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE DPDT 8A 12V
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Tube/Rail
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 33.3mA
Coil Voltage 12VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 8A
Switching Voltage 400VAC - Max
Turn On Voltage (Max) 8.4 VDC
Turn Off Voltage (Min) 1.2 VDC
Operate Time 8ms
Release Time 6ms
Features Insulation - Class F, Sealed - Fully
Mounting Through Hole
Termination Style PC Pin
Coil Power 400 mW
Coil Resistance 360 Ohms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 046495-RTE24012F
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RTE24012F CAD Model

Description

The TE Connectivity Potter & Brumfield Relays RTE24012F is a DPDT (2 Form C) general purpose relay with a coil voltage of 12VDC and a contact rating of 8A.

  • Coil Voltage: 12VDC
  • Contact Rating: 8A
  • Mounting Style: Through-Hole
  • Coil Resistance: 360 ohms
  • Sealed: Fully Sealed
  • Insulation Class: F
  • Switching Voltage: 400VAC
  • Turn On Voltage (Max): 8.4 VDC
  • Release Time: 6ms
  • Operate Time: 8ms
  • Packaging: Tube/Rail
  • Coil Power: 400mW
  • Supply and Demand Status: Limited
