IM01GR Real Image IM01GR label picture
Same model may have multiple batches, images only for reference.
IM01GR Real Image IM01GR label picture
IM01GR Real Image IM01GR label picture
Same model may have multiple batches, images only for reference.

IM01GR

Part No IM01GR
Manufacturer TE Connectivity
Catalog Signal Relays, Up to 2 Amps
Description RELAY TELECOM DPDT 2A 3V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Reel - TR
Status Active
Relay Type Telecom
Coil Type Non Latching
Coil Current 46.7mA
Coil Voltage 3VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Max) 2.25 VDC
Turn Off Voltage (Min) 0.3 VDC
Operate Time 3ms
Release Time 3ms
Features Sealed - Hermetically
Mounting SMD (SMT)
Termination Style Gull Wing
Coil Power 140 mW
Coil Resistance 64 Ohms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 133977-IM01GR
Family Name IM
Introduction Date November 19, 2007
ECCN EAR99
Country of Origin Portugal
Halogen Free Not Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IM01GR CAD Model

Description

The TE Connectivity Potter & Brumfield Relays IM01GR is a DPDT (2 Form C) telecom relay with a coil voltage of 3VDC and a coil resistance of 64 Ohms.

  • Contact Rating (Current): 2A
  • Switching Voltage: 250VAC, 220VDC - Max
  • Ideal for Use In: various telecom applications
  • Mounting: SMD (SMT)
  • Packaging: reel
  • Features: hermetically sealed design
  • Turn On Voltage (max): 2.25 VDC
  • Turn Off Voltage (min): 0.3 VDC
  • Operating Temperature Range: from -40°C to 85°C
