Same model may have multiple batches, images only for reference.
5917738-5 Real Image
Same model may have multiple batches, images only for reference.

5917738-5

Part No 5917738-5
Manufacturer TE Connectivity
Catalog D - SUB, D - SHAPED connectors
Description CONN RCPT 36POS R/A SOLDER / 36 Position Receptacle Connector Panel Mount, Through Hole, Right Angle Solder
Datasheet
5917738-5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>D-Shaped Connectors - Centronics
Mfr TE Connectivity AMP Connectors
Series CHAMP .050 II
Package Bulk
Product Status Obsolete
Connector Style Outer Shroud Contacts
Connector Type Receptacle
Number of Positions 36
Number of Rows 2
Mounting Type Panel Mount, Through Hole, Right Angle
Termination Solder
Flange Feature Housing/Shell (M2.6)
Features Board Lock
Contact Finish Gold
Contact Finish Thickness 3.94µin (0.10µm)
Base Product Number 5917738
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Names -5917738-5-SI
Standard Package 100
Win Source Part Number 1184529-5917738-5
Ultra Librarian 3D Model Ultra Librarian 5917738-5 CAD Model

Description

The CHAMP .050 II series from TE Connectivity AMP Connectors is a panel mount, through-hole, right-angle connector with 36 positions and 2 rows.

  • Feature: Board Lock
  • Feature: Flange for housing/shell (M2.6)
  • Connector Type: Receptacle
  • Contact Type: Outer Shroud
  • Termination: Solder
  • Contact Finish: Gold
  • Contact Finish Thickness: 3.94µin (0.10µm)
  • Package: Bulk
  • Standard Package: 100
  • ECCN: EAR99
  • MSL Level: 1 (Unlimited)
  • Lifecycle Status: Obsolete
