Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Boxes, Enclosures, Racks>Patchbay, Jack Panels
Mfr TE Connectivity AMP Connectors
Series AMP
Package Bulk
Type Modular Panel
Connector Type RJ45
Number of Positions 24
Number of Rows 1
Termination Style 110 Block
Base Product Number 406330
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4030
Other Names A122845,406330-1-ND,2266-406330-1
Standard Package 1
Win Source Part Number 1231931-406330-1
Ultra Librarian 3D Model Ultra Librarian 406330-1 CAD Model

Description

The TE Connectivity AMP Connectors modular panel with the part number 1231931-406330-1 has 24 positions and a 110 block termination style.

  • Manufacturer: TE Connectivity AMP Connectors
  • Positions: 24
  • Termination Style: 110 block
  • Rows: one-row
  • Connector Type: RJ45
  • Packaging: bulk
  • Operating Temperature Range: -40°C to 85°C
  • ECCN: EAR99
  • Ideal Use: boxes, enclosures, and racks for patchbay and jack panels
