1-178138-5

Part No 1-178138-5
Manufacturer TE Connectivity
Catalog Rectangular Connectors
Description CONN HDR 3POS R/A KEY-X TIN
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer TE Connectivity AMP Connectors
Packaging Bulk
Status Active
Connector Type Header
Contact Type Tab
Pitch - Mating 0.200" (5.08mm)
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Number of Positions 3
Number of Positions Loaded All
Number of Rows 1
Mounting Through Hole, Right Angle
Termination Solder
Fastening Type Detent Lock
Contact Length - Post 0.150" (3.81mm)
Insulation Height 0.368" (9.35mm)
Contact Shape Rectangular
Contact Finish - Mating Tin
Contact Finish Thickness - Mating 78.7μin (2.00μm)
Contact Finish - Post Tin
Insulation Material Thermoplastic, Polyester, Glass Filled
Features Board Lock
Temperature Range - Operating -55°C to 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Voltage Rating 600V
Applications General Purpose, Industrial
Win Source Part Number 197255-1-178138-5
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 1-178138-5 CAD Model

Description

Product Description

The 1-178138-5 is a high-quality electronic connector designed to provide excellent reliability and performance in various applications. Engineered to meet demanding industry standards, this connector ensures consistent connections even in challenging environments.

Features and Benefits

  • Durable construction for longevity
  • Superior conductivity ensuring minimal signal loss
  • Compact design for easy integration
  • Resistant to corrosion and environmental factors

Applications

  • Telecommunications
  • Industrial automation systems
  • Consumer electronics
  • Automotive control units
  • Medical devices

This connector is ideal for any project requiring robust and reliable connectivity solutions due to its advanced engineering and quality materials.
