The TDK-Lambda PAQ100S48-3R3/B HFP is a high-performance, quarter-brick isolated DC-DC converter. It is designed to provide a reliable and efficient power source for a wide range of applications. This converter accepts a wide input voltage range and delivers a tightly regulated output voltage, making it suitable for demanding environments.

Applications:

• Telecommunications equipment: Powering various components in telecom infrastructure.
• Industrial automation: Supplying power to control systems, sensors, and actuators.
• Test and measurement equipment: Providing stable power for sensitive measurement devices.
• Medical devices: Ensuring reliable power for critical medical applications (where applicable certifications are met).
• Networking equipment: Powering routers, switches, and other network devices.

Features:

• High Efficiency: Minimizes power loss and heat generation.
• Wide Input Voltage Range: Accommodates variations in input voltage.
• Isolated Output: Provides electrical isolation between input and output.
• Remote On/Off: Allows for convenient control of the converter.
• Output Voltage Trim: Enables fine-tuning of the output voltage.
• Overvoltage Protection: Protects the load from excessive voltage.
• Overcurrent Protection: Prevents damage from excessive current draw.
• Overtemperature Protection: Shuts down the converter if it overheats.
• Quarter-Brick Package: Industry-standard package for easy integration.
• RoHS Compliant: Compliant with Restriction of Hazardous Substances directive.

Benefits:

• Reliable Power: Ensures stable and consistent power delivery.
• Efficient Operation: Reduces energy consumption and operating costs.
• Flexible Integration: Easily integrates into various systems due to its standard package.
• Protection Features: Safeguards the load and the converter from damage.
• Meets Safety Standards: Designed to meet relevant safety certifications (verify specific certifications for your application).

Additional Details:

The PAQ100S48-3R3/B HFP has a nominal input voltage of 48VDC and provides an output voltage of 3.3VDC. The output current is rated at 30A, delivering a maximum output power of 100W. It operates over a wide temperature range, making it suitable for harsh environments. The isolation voltage between input and output is typically 2250VDC. The converter also features remote sense capability to compensate for voltage drops in the load wiring. The HFP suffix signifies that the product is a Half Function Packaged converter, optimized for high-performance and reliability. Review the manufacturer's datasheet for full specifications, safety information, and application notes.
