VLCF4020T-100MR85 TDK Corporation VLCF4020T-100MR85 real image VLCF4020T-100MR85 label picture
Same model may have multiple batches, images only for reference.
VLCF4020T-100MR85 TDK Corporation VLCF4020T-100MR85 real image VLCF4020T-100MR85 label picture
VLCF4020T-100MR85 TDK Corporation VLCF4020T-100MR85 real image VLCF4020T-100MR85 label picture
Same model may have multiple batches, images only for reference.

VLCF4020T-100MR85

Part No VLCF4020T-100MR85
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 10UH 850MA 185 MOHM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Packaging Reel - TR
Status Active
Type Wirewound
Material - Core Ferrite
Inductance 10μH
Tolerance ±20%
Current Rating 850mA
Current - Saturation 850mA
DC Resistance (DCR) 185 mOhm Max
Temperature Range - Operating -40°C to 105°C
Frequency - Test 100kHz
Mounting SMD (SMT)
Height - Seated (Max) 0.079" (2.00mm)
Win Source Part Number 036277-VLCF4020T-100MR85
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VLCF4020T-100MR85 CAD Model

Description

The TDK Corporation VLCF4020T-100MR85 is a wirewound inductor with a current rating of 850mA and an inductance of 10μH.

  • Core Material: Ferrite
  • Tolerance: ±20%
  • Applications: Inductors, coils, and chokes
  • DC Resistance: 185 mOhm Max
  • Temperature Range: -40°C to 105°C
  • Package: Reel - TR
  • Height: 0.079" (2.00mm) when seated
  • Supply and Demand Status: balanced
