The SLF6045T-100M1R6-3PF is a shielded power inductor from TDK Corporation, designed for DC-DC converter applications and power supply circuits. It offers a compact footprint with good current handling capabilities.

Applications

• DC-DC Converters
• Power Supplies for Portable Devices
• Tablet Computers
• Notebook Computers
• Smartphones

Features

• Shielded Construction
• Compact Size: 6.0 x 6.0 x 4.5 mm
• Inductance: 10 μH
• Tolerance: ±20%
• Rated Current: 1.6 A
• DC Resistance (DCR): 0.177 Ω (typical)
• Operating Temperature Range: -40°C to +105°C (Including self-temperature rise)

Benefits

• High Efficiency: Low DC resistance minimizes power loss, improving overall circuit efficiency.
• Compact Size: Allows for smaller and more densely packed circuit designs.
• Shielded Construction: Reduces electromagnetic interference (EMI) to nearby components.
• Stable Performance: Maintains consistent electrical characteristics across a range of temperatures.
• RoHS Compliant: Meets environmental standards for hazardous substances.

Technical Specifications

The SLF6045T-100M1R6-3PF uses a ferrite core material to provide the specified inductance. The shielded construction is crucial for minimizing electromagnetic interference (EMI) within the application. It is designed for surface mount reflow soldering. The component is delivered on tape and reel for efficient automated assembly. The specified rated current should not be exceeded in operation. Inductance is tested at 1 MHz.
