The CLF7045T-220M-D is a shielded wound ferrite inductor manufactured by TDK Corporation, designed for power circuit applications where space is limited and high efficiency is crucial. This inductor features a compact size, low DC resistance, and high current handling capabilities, making it ideal for use in portable devices and power supplies.

Applications

• DC-DC converters
• Power supplies for portable devices
• LED lighting drivers
• Noise filtering in power lines
• Buck, boost, and buck-boost converters

Features

• Wound ferrite core construction
• Compact size: 7.0 x 7.0 x 4.5 mm
• Inductance: 22 μH
• Tolerance: ±20%
• Low DC resistance
• High current handling capacity
• Shielded construction for reduced EMI

Benefits

• Improved power efficiency due to low DC resistance
• Space-saving design for compact devices
• Reduced electromagnetic interference (EMI)
• Stable inductance over a wide temperature range
• Reliable performance in demanding power applications

Additional Details
