ACM1513-551-2PL-TLHF

Part No ACM1513-551-2PL-TLHF
Manufacturer TDK Corporation
Catalog Common Mode Chokes
Description CMC 10A 2LN 550 OHM SMD / Common Mode Chokes Dual 550Ohm 100MHz 10A 0.004Ohm DCR SMD T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Manufacturer TDK Corporation
Packaging Reel - TR
Status Active
Filter Type Power Line
Number of Lines 2
Impedance @ Frequency 550 Ohm @ 100MHz
Current Rating (Max) 10A
DC Resistance (DCR) (Max) 4 mOhm
Voltage Rating - DC 50V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Height (Max) 0.236" (6.00mm)
Dimension Horizontal, 4 PC Pad
Win Source Part Number 007840-ACM1513-551-2PL-TLHF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name ACM
Introduction Date July 04, 2001
ECCN EAR99
Country of Origin China, Germany, United States of America
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian ACM1513-551-2PL-TLHF CAD Model

Description

Product Description

Designed with high-frequency applications in mind, the ACM1513-551-2PL-TLHF offers exceptional performance and reliability.

Features and Benefits

  • High-Frequency Capability: Optimized for applications involving high-frequency signals.
  • Enhanced Stability: Consistently reliable performance under varying conditions.
  • Energy Saving: Designed to minimize power usage.

Applications

  • RF Communication Systems
  • Signal Processing
  • Satellite Technology

Additional Details

This component is tailored for projects where high frequency and precise performance are critical, offering a blend of efficiency, stability, and reliability.
