Same model may have multiple batches, images only for reference.

SMCJ75

Name: SMCJ75
Brand: Taiwan Semiconductor
SKU: 668955
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SMCJ75
Manufacturer	Taiwan Semiconductor
Catalog	TVS - Diodes
Description	1500W, 92.7V, 10%, UNIDIRECTIONA
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	Taiwan Semiconductor
Series	SMCJ
Package	Tape & Reel
Product Status	Active
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	75V
Voltage - Breakdown (Min)	83.3V
Voltage - Clamping (Max) @ Ipp	134V
Current - Peak Pulse (10/1000µs)	11.7A
Power - Peak Pulse	1500W (1.5kW)
Power Line Protection	No
Applications	General Purpose
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	DO-214AB, SMC
Supplier Device Package	DO-214AB (SMC)
Base Product Number	SMCJ75
Standard Package	3,000 pcs
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	668955-SMCJ75
Ultra Librarian 3D Model	Ultra Librarian SMCJ75 CAD Model

Description

The 668955-SMCJ75 is a high-performance TVS diode designed for circuit protection against transient voltage spikes.

Voltage - Reverse Standoff (Typ): 75V
Voltage - Breakdown (Min): 83.3V
Application: General Purpose
Voltage - Clamping (Max) @ Ipp: 134V @ 11.7A
Power - Peak Pulse: 1500W (1.5kW)
Package Type: DO-214AB (SMC)
Mounting Type: Surface Mount
Product Status: Active
Manufacturer: Taiwan Semiconductor
