SMCJ22 Dc Components
Same model may have multiple batches, images only for reference.

SMCJ22

Part No SMCJ22
Manufacturer Taiwan Semiconductor
Catalog TVS - Diodes
Description 1500W, 27.1V, 10%, UNIDIRECTIONA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Taiwan Semiconductor
Series SMCJ
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 22V
Voltage - Breakdown (Min) 24.4V
Voltage - Clamping (Max) @ Ipp 39.4V
Current - Peak Pulse (10/1000µs) 39A
Power - Peak Pulse 1500W (1.5kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package DO-214AB (SMC)
Base Product Number SMCJ22
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 668912-SMCJ22
Ultra Librarian 3D Model Ultra Librarian SMCJ22 CAD Model

Description

The SMCJ22 is a unidirectional TVS diode designed for general-purpose circuit protection. It has a reverse standoff voltage of 22V and a breakdown voltage of 24.4V.

  • Reverse Standoff Voltage: 22V
  • Breakdown Voltage: 24.4V
  • Clamping Voltage @ Peak Pulse Current: 39.4V
  • Peak Pulse Power: 1500W
  • Diode Type: Unidirectional TVS Diode
  • Mounting Type: Surface Mountable
  • Package: DO-214AB (SMC)
  • Packaging: Tape and Reel
  • Standard Package: 3,000 pcs
  • Operating Temperature Range: -55°C to 150°C
  • Product Status: Active
  • Manufacturer: Taiwan Semiconductor
