MBR30200PT Sirectifier Semiconductors
Same model may have multiple batches, images only for reference.

MBR30200PT

Part No MBR30200PT
Manufacturer Taiwan Semiconductor
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 200V TO247
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Taiwan Semiconductor
Package Tube
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 30 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 100 µA @ 200 V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package TO-247AD (TO-3P)
Base Product Number MBR30200
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 633399-MBR30200PT
Ultra Librarian 3D Model Ultra Librarian MBR30200PT CAD Model

Description

The 633399-MBR30200PT is a fast recovery Schottky diode array designed for rectification applications in electronic circuits. It consists of a pair of common cathode diodes capable of handling an average rectified current of 30A per diode.

  • Average Rectified Current (per diode): 30A
  • Maximum DC Reverse Voltage: 200V
  • Forward Voltage Drop: 1.1V @ 30A
  • Current Leakage: 100µA @ maximum reverse voltage
  • Mounting Type: Through-hole
  • Package: TO-247-3
  • Standard Package: 50 pieces
