DBLS207G Real Image DBLS207G Real Image1 DBLS207G Real Image2 DBLS207G Real Image3
Same model may have multiple batches, images only for reference.
DBLS207G Real Image DBLS207G Real Image1 DBLS207G Real Image2 DBLS207G Real Image3
DBLS207G Real Image DBLS207G Real Image1 DBLS207G Real Image2 DBLS207G Real Image3
Same model may have multiple batches, images only for reference.

DBLS207G

Part No DBLS207G
Manufacturer Taiwan Semiconductor
Catalog Bridge Rectifiers
Description BRIDGE RECT 1PHASE 1KV 2A DBLS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 1 kV
Current - Average Rectified (Io) 2 A
Voltage - Forward (Vf) (Max) @ If 1.15 V @ 2 A
Current - Reverse Leakage @ Vr 2 µA @ 1000 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 4-SMD, Gull Wing
Supplier Device Package DBLS
Base Product Number DBLS207
Standard Package 1,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 584151-DBLS207G
Ultra Librarian 3D Model Ultra Librarian DBLS207G CAD Model

Description

The DBLS207G is a bridge rectifier diode designed for single-phase applications.

  • Type: Bridge Rectifier Diode
  • Application: Single-Phase
  • Maximum Forward Voltage: 1.15V @ 2A
  • Maximum Peak Reverse Voltage: 1kV
  • Reverse Leakage Current: 2μA @ 1000V
  • Mounting Type: Surface Mount
  • Package: 4-SMD, Gull Wing
  • Operating Temperature: -55°C to 150°C
  • Manufacturer: Taiwan Semiconductor
