BZD27C15P Vaishali Semiconductor
Same model may have multiple batches, images only for reference.

BZD27C15P

Part No BZD27C15P
Manufacturer Taiwan Semiconductor
Catalog Diodes - Zener - Single
Description SUB SMA, 1000MW, 6%, ZENER DIODE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Voltage - Zener (Nom) (Vz) 14.7 V
Tolerance ±6.12%
Power - Max 1 W
Impedance (Max) (Zzt) 10 Ohms
Current - Reverse Leakage @ Vr 1 µA @ 11 V
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 200 mA
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package Sub SMA
Base Product Number BZD27
Standard Package 10,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 574275-BZD27C15P
Ultra Librarian 3D Model Ultra Librarian BZD27C15P CAD Model

Description

The 574275-BZD27C15P is a single Zener diode with a nominal voltage of 14.7V and a maximum power of 1W.

  • Forward Voltage: 1.2V @ 200mA
  • Reverse Leakage Current: 1μA @ 11V
  • Tolerance: ±6.12%
  • Impedance: 10 Ohms
  • Temperature Range: -55°C to 175°C
  • Package: SOD-123
  • Application: voltage regulation and protection circuits
  • Standard Package: 10,000 pcs
