The TDA2040 from STMicroelectronics is a monolithic integrated circuit in Pentawatt package, intended for use as an audio class AB amplifier. This robust power amplifier offers high output current and has very low harmonic and crossover distortion. Designed to deliver 20 watts of power into a 4-ohm load over a wide frequency range, the TDA2040 is an ideal solution for high fidelity audio amplification requirements.
Key Features
- High Output Power: Capable of delivering 20W into a 4 ohm load with excellent sound quality.
- Wide Voltage Range: The operating supply voltage ranges from ±4.5V to ±25V, making it versatile for various audio applications.
- Low Distortion: Ensures pure sound reproduction with very low harmonic and crossover distortion.
- Short Circuit Protection: Features an in-built short circuit protection system that guards against sudden surges and faults.
- Thermal Overload Protection: Integrated thermal shutdown prevents damage from overheating.
- High Reliability: The device is designed with a robust construction for dependable performance.
Applications
The TDA2040 is suitable for a variety of audio applications, including:
- Hi-Fi audio amplifiers
- Music instruments amplifiers
- Home theater systems
- Active speakers
- Public address systems
Technical Specifications
Parameter
Value
Output Power
20W (4 ohm load)
Supply Voltage
±4.5V to ±25V
Package
Pentawatt
Operating Temperature
-20°C to 85°C
Overall, the TDA2040 is a reliable and efficient solution for high-quality audio amplification, offering the performance and features necessary for a wide range of audio equipment.
