The STPS2H100U is a high-efficiency power Schottky rectifier designed by STMicroelectronics, a leader in semiconductor solutions. This rectifier is well-suited for switch mode power supplies and high-frequency DC to DC converters. With its low forward voltage drop and high surge current capability, it is an excellent choice for applications requiring efficient energy conversion.

Key Features

• Voltage Ratings: The STPS2H100U is designed to handle a repetitive peak reverse voltage of up to 100V, making it suitable for a variety of applications.
• Current Capacity: This component can sustain an average forward current of 2A, providing a reliable solution for moderate power requirements.
• Low Power Loss: With its Schottky barrier technology, the STPS2H100U ensures low forward voltage drop, which translates into reduced power loss and improved efficiency.
• High Surge Capability: The device is capable of withstanding high surge currents, ensuring durability and robust performance during transient conditions.
• Compact Package: Encased in an SMB (DO-214AA) package, the STPS2H100U offers a compact footprint, which is beneficial for space-constrained applications.
• Operating Temperature: It can operate over a junction temperature range of -40°C to 150°C, accommodating a wide range of environmental conditions.

Applications

The STPS2H100U is versatile and can be used in various applications, including:

• Power supply units
• Adapters and battery chargers
• DC-DC converters
• Reverse polarity protection circuits
• Lighting systems
• Automotive applications

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STPS2H100U is manufactured with the highest standards, ensuring that it meets the stringent requirements of industrial and automotive-grade applications. Reliability is a cornerstone of ST's components, and this Schottky rectifier is no exception, providing consistent performance over its intended lifespan.

For detailed product specifications, application notes, and additional resources, customers are encouraged to visit the official STMicroelectronics website or contact their local sales office.
