STP16CPC26XTR LED Driver IC by STMicroelectronics

The STP16CPC26XTR is a cutting-edge LED driver integrated circuit (IC) produced by STMicroelectronics, a leader in semiconductor solutions. This high-performance LED sink driver is specifically designed for driving LED arrays and is well-suited for a wide range of applications including LED panels, display backlighting, and signage.

Key Features

• 16 Constant Current Output Channels: Each channel can sink up to 100mA, providing consistent brightness and color accuracy for LEDs.
• Adjustable Output Current: Through external resistors, users can easily set the current from 5mA up to 100mA to match the requirements of different LED configurations.
• Wide Voltage Range: The STP16CPC26XTR operates over a supply voltage range from 3.0V to 5.5V, making it versatile for various power supply scenarios.
• Error Detection: It includes open LED and short-circuit error detection mechanisms, which help to improve the reliability and longevity of the lighting application.
• Thermal Shutdown: An integrated thermal shutdown feature protects the device from overheating, further ensuring the safety and durability of the application.
• Serial Data Interface: Equipped with a shift register and a data latch structure, the IC supports serial data input and output, allowing multiple devices to be connected in series for expanded configurations.

Applications

The versatility of the STP16CPC26XTR makes it suitable for a wide range of LED driving applications, such as:

• LED display boards
• Backlighting for LCD TVs and monitors
• Interior and exterior lighting
• Indicator and signaling lights
• Automotive lighting systems

Product Packaging and Availability

The STP16CPC26XTR is available in a TSSOP24 package, ensuring a compact footprint for space-sensitive applications. As a testament to its reliability and performance, this LED driver IC is widely used in commercial and industrial lighting solutions. For detailed specifications, application notes, and additional resources, customers are encouraged to visit the STMicroelectronics website or contact their local sales representative.
