STP16CPC26TTR LED Driver by STMicroelectronics

The STP16CPC26TTR is a high-performance, monolithic, low-voltage 16-bit constant current LED sink driver from the renowned manufacturer STMicroelectronics. This device is part of their LED display product line and is specifically designed to deliver constant current to light up LEDs, ensuring uniform brightness across display panels and indicators. Its robust design and advanced features make it an ideal choice for driving LEDs in a wide range of applications, including signage, gaming, and industrial control panels.

Key Features

• Output Current Programmability: The STP16CPC26TTR allows users to program the output current from 5 mA up to 100 mA, providing flexibility for different LED brightness requirements.
• 16 Constant Current Output Channels: Each of the 16 channels can sink up to 100 mA, enabling the device to drive multiple LEDs simultaneously with consistent current, which is crucial for maintaining uniform brightness.
• Low Voltage Power Supply: The device operates with a power supply voltage as low as 3.3V, making it suitable for low-voltage applications.
• Error Detection: It features open and shorted LED error detection, which is essential for identifying and managing faults in LED arrays.
• Thermal Shutdown: An integrated thermal shutdown feature protects the device from overheating, ensuring a longer lifespan and reliable operation.
• Serial Interface: The STP16CPC26TTR is equipped with a serial interface for data input and a clock for easy connection and communication with microcontrollers or other control units.

Applications

The versatility of the STP16CPC26TTR makes it an excellent choice for a variety of applications that require high-quality and reliable LED driving solutions. Common applications include:

• LED Display Panels
• Channel Letters for Signage
• Decorative LED Lighting
• Instrument Panel Lighting
• Professional Lighting Systems

With its robust feature set and the reliability of STMicroelectronics, the STP16CPC26TTR is an optimal solution for designers and engineers who require a high-quality, constant current LED driver for their lighting projects. Its compact TSSOP package also ensures that it can be integrated into space-constrained designs without compromising performance.
