STM8S105C6T6 Microcontroller - STMicroelectronics

The STM8S105C6T6 is a high-performance 8-bit microcontroller produced by STMicroelectronics, which belongs to the STM8S series. This device is designed for a wide range of applications, and it offers an excellent balance of performance, robustness, and cost-effectiveness.

Key Features

• Core: The STM8S105C6T6 operates with a maximum frequency of 16 MHz, which is derived from an advanced STM8 core, ensuring efficient handling of tasks with its enhanced instruction set.
• Memory: It comes equipped with 32 Kbytes of Flash program memory, which offers endurance and reliability, along with 2 Kbytes of RAM and 1 Kbyte of EEPROM for data storage.
• Advanced Peripherals: This microcontroller includes a variety of peripherals such as 5 timers, two 16-bit timers with 2 channels each, an 8-bit timer, and a window watchdog timer. It also features an advanced control timer, which is perfect for motor control.
• I/O Ports: The device provides up to 37 I/O ports, allowing for a flexible connection to external devices and interfaces.
• Communication Interfaces: For communication purposes, it is equipped with interfaces like SPI, I2C, and UART, making it suitable for embedded systems that require serial communication.
• Analog to Digital Converter (ADC): A 10-bit ADC with up to 16 channels enables the microcontroller to convert analog signals into digital data for processing.

Applications

Due to its versatile nature, the STM8S105C6T6 can be used in a range of applications, including:

• Industrial control systems
• Consumer electronics
• Automotive applications
• Home appliances
• Complex embedded systems

Package and Quality

The STM8S105C6T6 is available in a 48-pin LQFP package, which provides a compact footprint while offering sufficient pins for various functionalities. STMicroelectronics ensures high-quality standards, with the device being compliant with industrial temperature ranges and offering robustness for different operational conditions.
