STM8S103F2P3TR Microcontroller by STMicroelectronics

The STM8S103F2P3TR is a highly-integrated microcontroller from STMicroelectronics that leverages the advanced STM8 core operating at a frequency of up to 16 MHz. This device is part of ST's 8-bit MCU family designed for cost-sensitive applications that require robust performance in a compact package.

The STM8S103F2P3TR comes in a TSSOP-20 package and is equipped with 8 KB of Flash program memory, which is ample for various applications. Alongside the Flash memory, it also features 1 KB of RAM and 128 bytes of EEPROM, which are non-volatile and can retain data without power. This combination of memories makes it suitable for applications that need to store parameters or calibration data that must persist after power cycles.

One of the key features of the STM8S103F2P3TR is its rich set of peripherals. It includes a versatile 10-bit analog-to-digital converter (ADC) with up to five channels, allowing it to interface with various sensors. For communication, it offers a UART for serial communication, I2C for multi-master communications, and SPI for high-speed synchronous data transfer. These interfaces make the MCU flexible and capable of handling a wide range of application requirements.

Additional features include an integrated single wire debug module, which simplifies development and troubleshooting. The device also provides up to 16 GPIO pins, which are highly configurable and include embedded interrupt capability, adding to the MCU's versatility. Its robust timer system includes a 16-bit timer, two 8-bit timers, and a watchdog timer, which helps to ensure system reliability and allows for complex timing operations.

The STM8S103F2P3TR operates over a wide voltage range of 2.95V to 5.5V, ensuring compatibility with both 3.3V and 5V systems. Its industrial temperature range from -40°C to 85°C makes it suitable for harsh environments.

STMicroelectronics provides comprehensive development tools and software libraries to support the STM8S103F2P3TR, which helps to reduce development time and cost. Whether it's for home appliances, industrial controls, or automotive systems, this microcontroller offers a balance of performance, power consumption, and peripherals, making it an excellent choice for a myriad of embedded applications.
