STM8L151C8T6 Microcontroller - STMicroelectronics

The STM8L151C8T6 is a cutting-edge 8-bit microcontroller from STMicroelectronics that targets energy-saving applications. This microcontroller is part of the STM8L ultra-low-power family and is designed to deliver high performance and robustness with a wide range of peripherals, while maintaining exceptional power efficiency.

At the heart of the STM8L151C8T6 is an advanced STM8 core operating at up to 16 MHz. It is complemented by 64 KB of Flash program memory, 2 KB of RAM, and 1 KB of data EEPROM. This combination of memory features ensures ample space for complex applications and data storage, while the EEPROM provides reliable storage for critical data that must be preserved during power cycles.

The device offers a rich set of peripherals, including:

• Integrated LCD driver that supports up to 8x40 or 4x44 segments, making it an ideal choice for applications with display requirements.
• Multiple communication interfaces: USART, SPI, and I2C, facilitating easy connection to other devices and sensors.
• 12-bit ADC with up to 21 channels, providing precise analog to digital conversion for a wide range of sensor inputs.
• Two 16-bit timers and one 8-bit timer, which can be used for timing operations, pulse generation, and PWM output.

Security and data integrity are ensured with a unique ID and a true data EEPROM with read/write protection. The STM8L151C8T6 operates within a supply voltage range of 1.8V to 3.6V, and its ultra-low-power modes include low power run, low power wait, and halt, which enable the design of applications with extended battery life.

This microcontroller is housed in an LQFP48 package, offering a compact footprint for space-constrained applications. Its temperature range from -40°C to +85°C allows for operation in harsh environments, making it suitable for industrial, consumer, and medical applications.

Overall, the STM8L151C8T6 from STMicroelectronics is a versatile and efficient solution for designers looking to create sophisticated applications without compromising on power consumption or performance.
