The STM6719TWWB6F is a sophisticated microprocessor reset circuit device developed by STMicroelectronics, a leader in semiconductor solutions. This compact and high-performance component is designed to monitor the supply voltage of microprocessors (µP) and digital systems, providing a reliable reset signal to the µP during power-up, power-down, and brown-out conditions. The STM6719TWWB6F ensures that the µP resets in a proper and orderly fashion, protecting the system from data corruption and ensuring a stable operation.
This device features a dual/triple voltage monitor with manual reset capability. The precision monitoring of supply voltages makes it an ideal choice for systems that require a high level of reliability and accuracy. The STM6719TWWB6F operates over a wide range of supply voltages, from 1.65V to 5.5V, and offers low supply current, making it suitable for battery-powered and portable applications.
With its built-in hysteresis, the STM6719TWWB6F avoids false resets, ensuring that the system only resets when necessary. The device also provides an active-low reset output, which remains asserted until the supply voltage returns to a stable condition and for a specified period afterward, allowing the system to recover fully before resuming operation.
The STM6719TWWB6F is available in a small TSSOP8 package, which is advantageous for space-constrained applications. It is also characterized for operation over the full industrial temperature range of -40°C to +85°C, which means it can be used in a wide variety of environments and applications, including industrial controls, automotive systems, and consumer electronics.
Key features of the STM6719TWWB6F include:
- Dual/triple voltage monitoring
- Manual reset input
- Low supply current
- Wide operating voltage range
- Active-low reset output
- Built-in hysteresis
- Small TSSOP8 package
- Industrial temperature range
STMicroelectronics' commitment to innovation is reflected in the STM6719TWWB6F, offering robust protection for digital systems and ensuring the longevity and reliability of your electronic products.
