STH240N75F3-6 Power MOSFET by STMicroelectronics

The STH240N75F3-6 is a high-performance, N-channel Power MOSFET designed and manufactured by STMicroelectronics, a leader in semiconductor solutions. This MOSFET is part of ST's MDmesh™ F3 series, which is well-known for its excellent energy efficiency and thermal performance. The device is specifically engineered to handle high power and high efficiency requirements in a wide range of applications.

Key Features:

• High Voltage Capability: The STH240N75F3-6 can sustain a drain-source voltage (V<sub>DS) of up to 75V, making it suitable for high voltage applications.
• Low On-Resistance: With an on-resistance (R<sub>DS(on)) as low as 0.036 Ohm, this MOSFET ensures minimal power loss and improved efficiency in electronic circuits.
• High Current Capacity: It can handle a continuous drain current (I<sub>D) of up to 120A, which is ideal for applications requiring high current flow.
• Improved Switching Performance: The fast switching speed of the STH240N75F3-6 reduces switching losses and enhances overall performance.
• Enhanced Thermal Performance: The device features an excellent figure of merit (FOM) and a low gate charge (Q<sub>g), which contributes to its superior thermal management capabilities.

Applications:

The STH240N75F3-6 Power MOSFET is versatile and can be used in a variety of applications, including:

• Switching power supplies and DC/DC converters
• Solar inverters and photovoltaic systems
• Motor drives and controllers
• Automotive applications and high-performance power management systems

Package Information:

The device is available in a TO-247 package, which is known for its robustness and ability to handle high power densities. The TO-247 package also provides excellent thermal conduction and electrical isolation, making it a reliable choice for demanding environments.

Conclusion:

STMicroelectronics' STH240N75F3-6 is an advanced Power MOSFET that offers a combination of high voltage capacity, low on-resistance, and high current handling. Its fast switching capabilities and thermal efficiency make it an ideal choice for designers looking to optimize power management in their applications. Whether it's for industrial, automotive, or renewable energy sectors, the STH240N75F3-6 is engineered to deliver superior performance and reliability.
