The STEVAL-PCC015V1 from STMicroelectronics is a demonstration board designed for the evaluation of USB Type-C and Power Delivery solutions. This advanced product enables developers and engineers to explore the capabilities of STMicroelectronics' USB-C Power Delivery technology, providing a versatile platform for designing and testing USB-C applications.

Key Features

• USB Type-C Interface: The board features a USB Type-C port that supports reversible plug orientation and cable direction, enhancing user convenience and reducing wear and tear.
• Power Delivery Compliance: It complies with the USB Power Delivery (PD) 2.0 specification, enabling higher power capabilities and expanded flexibility in power management across various devices.
• High Power Support: The STEVAL-PCC015V1 is capable of handling up to 100W of power delivery, making it suitable for applications that require significant power, such as charging laptops or other high-power devices.
• Programmable Power Supply (PPS): The board supports PPS, allowing for fine-grained control over the voltage and current delivered to the USB device, which can optimize charging efficiency and reduce heat generation.

Applications

The versatility of the STEVAL-PCC015V1 makes it ideal for a wide range of applications, including:

• Power adapters and chargers for laptops, tablets, and smartphones
• Multi-port charging stations and hubs
• USB-C docking stations
• Embedded systems requiring USB-C connectivity

Technical Specifications

The board is equipped with robust protection features such as over-voltage, over-current, and short-circuit protection, ensuring reliable operation under various conditions. It also includes an STUSB1602 USB-C controller IC, which manages the USB Power Delivery protocol and offers system designers a comprehensive solution with certified interoperability.

Design Support

STMicroelectronics provides extensive design support for the STEVAL-PCC015V1, including hardware documentation, firmware libraries, and application notes. These resources are designed to help users accelerate the development process and leverage the full potential of the board in their own USB-C and Power Delivery applications.
