The STEVAL-CCA018V1 from STMicroelectronics is a state-of-the-art demonstration board designed specifically for audio applications. It showcases the performance capabilities of the TDA7498E, a dual BTL class-D audio amplifier, which is intended for high-quality sound systems and home theater setups.

Key Features

• High Output Power: The TDA7498E is capable of delivering up to 160W of output power per channel into an 8 Ohm speaker at a THD of 10%, ensuring powerful and clear audio reproduction.
• Wide Supply Voltage Range: The board operates over a wide supply voltage range (from 12V to 36V), making it suitable for a variety of applications from car audio to home entertainment systems.
• Efficient Class-D Operation: The class-D architecture provides high efficiency, reducing power loss and minimizing the need for heat dissipation, which in turn allows for a more compact system design.
• Differential Inputs: Differential input capability helps to reject common-mode noise, leading to improved signal integrity and audio quality.
• Single-Ended or BTL Configuration: The TDA7498E can be configured in either Single-Ended or BTL (Bridge-Tied Load) mode, offering flexibility in the design of the audio system.

Applications

The STEVAL-CCA018V1 is ideal for a wide range of audio applications, including:

• Home theater systems
• Active speakers and subwoofers
• Soundbars and TV audio systems
• Professional audio equipment

Design and Integration

Designed with practicality in mind, the STEVAL-CCA018V1 is equipped with a range of features to facilitate easy integration into existing systems. These include overcurrent protection, thermal protection, and a standby feature that helps to reduce power consumption when not in active use. The board is also RoHS compliant and designed to meet international safety standards.

Overall, the STEVAL-CCA018V1 is an excellent choice for audio enthusiasts and professionals looking for a reliable and high-performing solution to drive their speaker systems.
