ST26C32AB - Quad Differential Line Receiver

The ST26C32AB from STMicroelectronics is a quad differential line receiver designed to meet the standards of RS422 and RS423 for balanced and unbalanced digital data transmission, while offering a high level of performance in terms of data rate and noise immunity. This integrated circuit is particularly well-suited for long-distance and noisy environment applications where reliable signal integrity is paramount.

Key Features

• Compatibility: Meets the requirements of RS422 and RS423 standards.
• Channels: Includes four independent receiver channels.
• Speed: Capable of supporting high-speed data rates.
• Supply Voltage: Operates with a single 5V power supply.
• Input Sensitivity: Features ±200 mV differential input sensitivity.
• Input Resistance: Offers a 7 kΩ minimum input impedance.
• Functional Range: Operates over a wide temperature range.
• Output: TTL/CMOS compatible output levels.
• Packaging: Available in different package options to suit various design requirements.

Applications

The ST26C32AB is ideal for use in a variety of communication systems and data transmission applications, including:

• Digital data communication systems
• Telecommunication systems
• Networking equipment
• Industrial control and factory automation
• Instrumentation and measurement devices

Quality and Reliability

STMicroelectronics ensures that the ST26C32AB is manufactured to the highest quality standards, providing reliable performance for critical applications. The device is also supported by STMicroelectronics' technical documentation and application support, making integration into your design as seamless as possible.

Ordering Information

To order the ST26C32AB or to obtain detailed specifications, please visit the STMicroelectronics website or contact your local STMicroelectronics sales office.
