The SMBJ48CA-TR from STMicroelectronics is a robust Transient Voltage Suppressor (TVS) diode, designed to protect sensitive electronic equipment from voltage transients induced by system inductance, lightning, and other transient voltage events. This device is particularly suitable for use in space-constrained applications, owing to its compact SMB (DO-214AA) package.

Key Features

• Bi-directional Protection: This TVS diode can clamp transient voltages in both positive and negative directions, providing symmetrical protection that is ideal for AC applications or where the polarity is reversible.
• Stand-off Voltage: The SMBJ48CA-TR has a stand-off voltage of 48V, making it suitable for a variety of interfaces that operate around this voltage level.
• Peak Pulse Power: With a peak pulse power dissipation of 600W (10/1000μs surge), it can handle significant power surges, ensuring the protection of the connected device.
• Fast Response Time: The device features a fast response time, typically in the order of picoseconds, ensuring quick clamping of transient voltages before they can cause damage to the circuit.
• Low Incremental Surge Resistance: The low resistance of the diode during surge events helps to minimize the voltage drop across it, thereby better protecting the circuit.
• Operating Temperature Range: The diode operates effectively over a wide temperature range from -55°C to +150°C, suitable for various industrial and commercial environments.

Applications

The SMBJ48CA-TR is versatile and can be used in a variety of applications, including:

• Power supply protection
• AC/DC applications
• Data line protection
• Industrial electronics
• Telecommunication systems
• Consumer electronics

Quality and Reliability

STMicroelectronics is renowned for its commitment to quality and reliability, and the SMBJ48CA-TR is no exception. It is compliant with the ISO 9001 and ISO 14001 standards, ensuring a high level of product excellence and environmental consideration. Additionally, it is RoHS compliant and free from hazardous substances, making it a suitable choice for eco-conscious applications.
