SMBJ33CA-TR Transient Voltage Suppressor from STMicroelectronics

The SMBJ33CA-TR is a state-of-the-art transient voltage suppressor (TVS) diode designed by STMicroelectronics, a global leader in semiconductor solutions. This robust component is specifically engineered to protect sensitive electronic equipment from voltage spikes and transients induced by lightning, load switch, and other disruptive events. With its bidirectional clamping feature, the SMBJ33CA-TR is an ideal choice for safeguarding systems where reverse polarity may occur.

Key Features

• Stand-Off Voltage: The SMBJ33CA-TR has a stand-off voltage of 33V, providing a secure threshold before clamping occurs.
• Peak Pulse Power: It can handle peak pulse power dissipation of 600W (10/1000 μs), ensuring high power spikes are effectively managed without compromising the integrity of the circuit.
• Clamping Voltage: With a maximum clamping voltage of 53.3V at 11.2A, this device offers reliable protection against transient overvoltage conditions.
• Fast Response Time: The TVS diode offers an exceptionally fast response time to transient events, typically in the picosecond range, which is crucial for modern high-speed circuits.
• Low Leakage Current: The low leakage current of the SMBJ33CA-TR minimizes power loss when the device is in standby mode, contributing to the overall energy efficiency of the system.
• Package: It comes in a compact SMB (DO-214AA) surface-mount package, which is well-suited for automated assembly processes and saves valuable board space.
• Certifications: The device meets the ISO 7637-2 pulse 5a and 5b standards and complies with IEC 61000-4-2 and IEC 61000-4-5 surge specifications.

Applications

The SMBJ33CA-TR is versatile and can be used across a wide range of applications, including:

• Power supply lines
• Communication systems
• Automotive electronics
• Industrial control systems
• Consumer electronics
• Portable devices

With its robust design and reliable performance, the SMBJ33CA-TR from STMicroelectronics is an excellent choice for designers and engineers looking to enhance the durability and longevity of their electronic products. By integrating this TVS diode into your design, you can ensure that your circuits are well-protected against the unpredictable nature of transient voltage events, thereby improving system reliability and customer satisfaction.
