Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Technology LDMOS
Frequency 500MHz
Gain 14.5dB
Voltage - Test 12.5 V
Current Rating (Amps) 7A
Current - Test 200 mA
Power - Output 25W
Voltage - Rated 40 V
Case / Package PowerSO-10RF Exposed Bottom Pad (2 Formed Leads)
Supplier Device Package PowerSO-10RF (Formed Lead)
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1510457-PD55025TR-E
Ultra Librarian 3D Model Ultra Librarian PD55025TR-E CAD Model
