STMicroelectronics M24C16-RMN6TP EEPROM

The M24C16-RMN6TP is a high-performance 16-Kbit serial EEPROM (Electrically Erasable Programmable Read-Only Memory) from STMicroelectronics, renowned for its robustness and reliability. This memory device is part of the M24C series, which offers a wide range of flexible I²C-compatible EEPROM products.

Designed with an architecture of 2048 x 8 bits, the M24C16-RMN6TP provides a substantial amount of data storage while maintaining a small physical footprint, making it an ideal choice for a multitude of applications where efficient data storage is crucial. It operates over a voltage range of 1.8V to 5.5V, ensuring compatibility with both low-power and standard applications.

One of the key features of this EEPROM is its I²C bus compatibility, which allows for easy integration into most microcontroller-based systems. The two-wire serial interface supports a bidirectional data transfer protocol, making communication with the memory straightforward and efficient. Additionally, the device supports a maximum clock frequency of 400 kHz (Fast-mode), enabling swift data access and programming operations.

The M24C16-RMN6TP is equipped with Write Control features such as Byte and Page Write (up to 16 bytes), which contribute to its versatility in various programming scenarios. The self-timed write cycle with auto-erase ensures that data integrity is maintained during write operations without the need for complex programming algorithms.

For security and data protection, the M24C16-RMN6TP offers a hardware write protect feature. This ensures that the stored data cannot be altered when the protection is enabled, providing an additional layer of security against unintentional writes, particularly in sensitive applications.

The device is delivered in an 8-pin MiniMap (MLP8) package, which is RoHS compliant and designed for surface-mount technology (SMT), making it suitable for automated manufacturing processes. Its compact form factor and low power consumption make it a preferred choice for portable and power-sensitive applications in various industries, including consumer electronics, automotive, industrial automation, and telecommunications.

With its robust design, compatibility with I²C bus standards, and a comprehensive set of features, the M24C16-RMN6TP EEPROM from STMicroelectronics is a reliable and efficient solution for designers looking to enhance their systems with non-volatile memory storage.
